Jeep 3.1 TD (140 Hp) 4x4 Automatic
General information
| Power | 140 Hp @ 3600 rpm. |
|---|---|
| Torque | 384 Nm @ 1800 rpm. |
| Acceleration 0 - 100 km/h | 14 sec |
| Maximum speed | 170 km/h |
| Brand |
Jeep
|
|---|---|
| Model |
Grand Cherokee
|
| Generation |
Grand Cherokee II (WJ)
|
| Modification (Engine) |
3.1 TD (140 Hp) 4x4 Automatic
|
| Start of production |
1999 year
|
| End of production |
2001 year
|
| Powertrain Architecture |
Internal Combustion engine
Powertrain architecture classifies the propulsion technology of the vehicle, such as internal combustion, electric (BEV), or hybrid.
|
| Body type |
SUV
Body type refers to the structural design and shape of the vehicle (such as Sedan, Hatchback, SUV, or Coupe).
|
| Seats |
5
Seat count specifies the maximum passenger capacity the vehicle is legally approved to transport at once.
|
| Doors |
5
Door count indicates the total number of entry points for passengers and cargo access (e.g., 3-door, 5-door).
|
FAQ
Performance specs
| Fuel consumption (urban) NEDC |
14.9 l/100 km
|
|---|---|
| Fuel consumption (extra-urban) NEDC |
9.7 l/100 km
|
| Fuel consumption (combined) NEDC |
11.6 l/100 km
|
| CO2 emissions NEDC |
308 g/km
|
| Fuel Type |
Diesel
Fuel type defines the primary source of energy required by the vehicle’s engine (petrol, diesel, electricity, hybrid, LPG, etc.).
|
| Acceleration 0 - 100 km/h |
14 sec
The 0-100 km/h sprint time measures how quickly the vehicle accelerates from a standstill. It is a key indicator of raw performance and responsiveness.
|
| Acceleration 0 - 62 mph |
14 sec
The 0-100 km/h sprint time measures how quickly the vehicle accelerates from a standstill. It is a key indicator of raw performance and responsiveness.
|
| Acceleration 0 - 60 mph (Calculated by User) |
13.3 sec
|
| Maximum speed |
170 km/h
Maximum speed represents the upper limit of velocity the vehicle can reach, limited by gear ratios, engine power, and aerodynamic resistance.
|
| Weight-to-power ratio |
13.6 kg/Hp, 73.8 Hp/tonne
|
| Weight-to-torque ratio |
4.9 kg/Nm, 202.3 Nm/tonne
|
Engine specs
| Power |
140 Hp @ 3600 rpm.
|
|---|---|
| Power per litre |
44.8 Hp/l
Power per litre (specific power) measures the engine power relative to its displacement. A higher value indicates advanced efficiency and engineering quality.
|
| Torque |
384 Nm @ 1800 rpm.
Torque represents the engine’s rotational force, which determines pulling power. High torque ensures responsive acceleration and stronger uphill performance.
|
| Engine layout |
Front, Longitudinal
Engine layout defines the position and alignment of the engine block. This layout affects the car’s weight distribution, handling, and interior cabin space.
|
| Engine Model Code |
EXA
|
| Engine displacement |
3124 cm3
Engine displacement represents the combined volume of all cylinders. It is a direct indicator of engine size and baseline performance potential.
|
| Number of cylinders |
5
Cylinder count represents the number of combustion chambers. More cylinders generally result in smoother operation and a refined engine note.
|
| Engine configuration |
Inline
|
| Cylinder bore |
92 mm
|
| Piston stroke |
94 mm
|
| Compression ratio |
21:1
|
| Number of valves per cylinder |
2
Valves per cylinder control the airflow into and exhaust out of the engine. More valves improve high-RPM breathing and performance.
|
| Fuel injection system |
Precombustion chamber injection
|
| Engine aspiration |
Turbocharger, Intercooler
Aspiration describes how the engine draws air into its cylinders, distinguishing naturally aspirated setups from turbochargers or superchargers.
|
| Valvetrain |
OHV
|
| Engine oil capacity |
7.2 l
|
| Coolant |
12 l
|
Space, Volume and weights
| Kerb Weight |
1898-1966 kg
Curb weight is a key parameter affecting fuel consumption, handling agility, acceleration times, and stopping distances.
|
|---|---|
| Max. weight |
2505 kg
Curb weight is a key parameter affecting fuel consumption, handling agility, acceleration times, and stopping distances.
|
| Max. load |
539-607 kg
|
| Trunk (boot) space - minimum |
1104 l
|
| Trunk (boot) space - maximum |
2047 l
|
| Fuel tank capacity |
78 l
|
| Max. roof load |
68 kg
|
| Permitted trailer load with brakes (12%) |
3360 kg
|
| Permitted trailer load without brakes |
750 kg
|
| Permitted towbar download |
140 kg
|
Dimensions
| Length |
4611 mm
|
|---|---|
| Width |
1858 mm
|
| Width including mirrors |
2180 mm
|
| Height |
1805 mm
|
| Wheelbase |
2690 mm
|
| Front track |
1511 mm
|
| Rear / Back Track |
1511 mm
|
| Ride height (ground clearance) |
210 mm
|
| Drag coefficient (Cd) |
0.45
|
| Minimum turning circle (turning diameter) |
11.1 m
|
| Approach angle |
36.7°
|
| Departure angle |
28.6°
|
| Ramp/Breakover angle |
22.6°
|
Drivetrain, brakes and suspension specs
| Drivetrain Architecture |
The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drivetrain type specifies which wheels receive power from the engine. This affects road grip, cornering, and stability on slippery surfaces.
|
|---|---|
| Drive wheel |
All wheel drive (4x4)
Drivetrain type specifies which wheels receive power from the engine. This affects road grip, cornering, and stability on slippery surfaces.
|
| Number of gears and type of gearbox |
4 gears, automatic transmission
|
| Front suspension |
Coil spring, Rigid axle suspension, Transverse stabilizer
The suspension system absorbs road bumps, providing cabin comfort and keeping tires firmly planted on the road surface.
|
| Rear suspension |
Rigid axle suspension, Transverse stabilizer, Trailing arm, Coil spring
The suspension system absorbs road bumps, providing cabin comfort and keeping tires firmly planted on the road surface.
|
| Front brakes |
Ventilated discs, 305 mm
The brake system is a vital safety component that uses friction to slow down or bring the vehicle to a complete stop.
|
| Rear brakes |
Disc, 305 mm
The brake system is a vital safety component that uses friction to slow down or bring the vehicle to a complete stop.
|
| Assisting systems |
ABS (Anti-lock braking system)
|
| Steering type |
Cone worm with recirculation balls
|
| Power steering |
Hydraulic Steering
|
| Tires size |
225/75 R16
Tire size specifies the tread width, aspect ratio, and rim diameter, affecting the balance between handling grip and ride comfort.
|
| Wheel rims size |
7J x 16
|
