Fiat / FCA
🟡 Medium
Fiat / FCA
P0480
FIAT FIAT Cooling Fan 1 Control Circuit Fault
The P0480 fault on your Fiat / FCA indicates a FIAT FIAT Cooling Fan 1 Control Circuit Fault. Your Fiat / FCA has registered an anomaly during a diagnostic self-test, indicating the system is struggling to reach its target operating range.
Brand
Fiat / FCA
Fault Code
P0480
Severity
🟡 Medium
Models
500, Punto, Bravo, Alfa 147/156/159, Doblo, Ducato
🛠️ Diagnostic Overview
Difficulty Level
🛠️🛠️
Medium (Moderate)
Estimated Time
⏱️ 1-2 Hours
🧰 Required Tools
- ✓ Socket Wrench & Hand Tools
- ✓ Replacement Fuses
⚠️ Possible Causes
- • Burned out fan resistor (extremely common)
- • Blown fuse
- • Failed fan motor.
🔧 Recommended Fixes
- → Check the ceramic fan resistor located on the radiator shroud. If it looks cracked or burnt, replace it—this is a very specific and common Fiat fault.
🚗 Commonly Affected Vehicles
